Operating
system |
Win2000/Xp/Linux |
|
System |
NTSC
- PAL -
SECAM |
|
User interface |
GUI
single mouse
(No keyboard) |
|
Network
interface |
10/100base
T-Ethernet |
|
Power restoration |
Auto
re-boot
1 minute
from power
up |
|
Security |
2
Passwords
+ remote
setup |
|
Video inputs |
4
x BNC 1V
pp 75 Ohms |
|
Video output |
D
type VGA/TV
out |
|
Quad monitoring |
Real
Time/Ch
320 x 240/30fps |
|
Single monitoring |
Near
real time
/Ch 640
x 480 /15fps |
|
Display
adjustments |
Brightness,
Contrast
in single
user mode |
|
Recording
resolution |
320
x 240 and
160 x 120 |
|
Compression |
MPEG4 |
|
Compression
quality |
10%
(Lower for
Hi image
Q) 320 x
240 = 0.5Kb |
|
Display
storage |
Remaining
color coded
/normal/recycle |
|
Playback
speed (fast) |
Forward/reverse:
up to x
64 frame
by frame |
|
Display |
Year/Date/Month/Hour/Minute/Second |
|
Recording
speed |
11
ranges/Ch.
@ 60fps/system |
|
HDD storage |
Options
80 and 120
Gb |
|
Motion dtecetion |
10
degrees
per camera |
|
Pre-scheduled
recording |
7/24
Continuous/Motion
detection/None |
|
Stamp code |
Date/Time
permanent |
|
Playbeck
selection |
Open/
Close/ Expand/Scroll |
|
Playback
mode |
Play/Pause/Step |
|
Uimage adjustment |
Brightness/Contrast/Invert/Zoom |
|
Remote monitoring |
Intenet
Web Browser
- Hibit
rate 512K=12fps
(3/Ch.) |
|
Playbeack |
MPEG4
streaming |
|
Interface |
LAN/Internet/Intranet/Dialup |
|
Alarm input |
4
x NC/NO
digital
input |
|
Alarm Output |
4
x NO/NC
relay out |
|
Recommended
backup |
DIT
HDD replacement |
|
Power requirement |
100~240V
AC 50/60Hz |
|
Weight |
5Kg |
|
Dimensions |
175
x 190 x
280mm |
|
Operating
Temperature |
-5 to +45C |
|
Storage
Temperature |
-20 to +70C |
